Lithium Battery ER18505
video
Lithium Battery ER18505

Lithium Battery ER18505

Model: ER18505
Nominal voltage: 3.6V
Weight: Approx. 32g
Storage temperature: Max. 30℃
Shape: A

Description

Introduction

This is a very popular battery type. It is different from other recharged batteries. It is a non -charging battery. This battery uses a lithium metal compound as an anode material, which can greatly increase the energy storage density and service life of the battery. Secondly, its primary feature is its high energy density and long life. It can be fully charged in a relatively short period of time, and only requires less power to meet the work requirements of electronic equipment. In addition, according to its design, the battery does not produce much heat when providing high power output, so there is no need to perform additional heat dissipation. Finally, Lithium Battery ER18505 have many other advantages, such as long -term storage performance, extremely low self -discharge rate, and a wide range of working temperature range. This makes it have a wide range of uses in many applications, including sensors, smart meters, medical devices, remote controls, smart locks, wireless transmission devices, and so on.


Advantage

First of all, the energy density of Lithium Battery ER18505 is higher than that of traditional batteries, so it can provide more energy while maintaining the same volume, because it uses advanced lithium -ion battery technology. In addition, this battery has high reliability and stability, is not easy to leak, is very safe to use, and the self -discharge rate is very low during storage. This allows it to store it for a long time. Lost. Secondly. Our products are widely used in many fields, such as wireless communication, smart meters, medical equipment, smart instruments, and so on. Finally, with its excellent performance and reliability, we have become an indispensable energy source for modern electronics.


Electrical Characteristics


Model

ER18505

Nominal voltage

3.6V

Nominal capacity

4000mAh (At 2mA, +25°C 2.0V cut off. Discharge capacity may vary with current drain, temperature and cut off voltage)

Max. continuous current

130mA (at 25°C to 2.0V cut-off )

Max. pulse current

180mA

Operating temperature range

-60℃~+85℃

Weight

Approx. 32g

Storage temperature

Max. 30℃

Shape

A

Dimension(max.)

18.5*50.5mm(Diameter*Height)

Battery type

Bobbin Type

Electrolyte/Chemistry

Lithium Thionyl Chloride(Li-SOCl2)

Brand

Ruizhi, Beleader, OEM acceptable


Certification


Compliance with the European directive CE & RoHS

MSDS, UN38.3 Report, ISO9000


ER18505
