Lithium Battery ER18505M
video
Lithium Battery ER18505M

Lithium Battery ER18505M

Model: ER18505M
Nominal voltage: 3.6V
Nominal capacity: 3500mAh
Max. continuous current: 1000mA
Max. pulse current: 2000mA

Description

Lithium battery ER18505M is a versatile and reliable power supply that provides excellent performance in a variety of demanding applications. Its high energy density, long lifetime, wide operating temperature range, high discharge rate, and low self-discharge rate make it an excellent choice for different types of devices such as remote sensors, security systems, and medical equipment. Its shell is made of high-quality stainless steel, which has strong corrosion resistance and water resistance, and can be used in various corrosive and humid environments. The advanced lithium thionyl chloride electrolyte is used inside the battery, which has the characteristics of non-flammability and long life, so it can ensure safety and durability. In addition, this battery is designed with wire connector terminals for user convenience. Welcome customers in need to come to cooperate!


Electrical Characteristics


Model

ER18505M

Nominal voltage

3.6V

Nominal capacity

3500mAh

Max. continuous current

1000mA

Max. pulse current

2000mA

Operating temperature range

-60℃~+85℃

Weight

Approx. 32g

Storage temperature

Max. 30℃

Shape

A

Dimension(max.)

18.5*50.5mm(Diameter*Height)

Battery type

Spiral Type

Electrolyte/Chemistry

Lithium Thionyl Chloride(Li-SOCl2)

Brand

Ruizhi, Beleader, OEM acceptable


Key Features


1. Compared with the same type of battery, this battery can release a stronger current with the same volume, so it can easily meet the needs of various high-power devices.

2. Thanks to its safety function and thoughtful sealing design, this Lithium Battery ER18505M has strong stability and reliability, and is not easily affected by the external environment.

3. The design of the wire connector terminal allows the user to easily connect it to the device, which saves time and effort.

4. This battery pack has a very wide range of applications. It can be used in various devices that require high-performance power supplies, such as wireless communication equipment, security equipment, smart home equipment, handheld test instruments, etc.

5. The working voltage of this battery pack is around 3.6V, the capacity is 3500mAh, and its service life can reach up to 10 years, which is cost-effective.


Main Application


Smart wireless device, Water metering equipment, smoking alarm device, Remote controller equipment


ER18505M


WARNING Safety


• Do not remove the cells from their original packing before use

• Do not store the cells in bulk in order to avoid accidental short circuit.

• Do not disassemble

• Do not recharge.

• Do not solder directly in the cell.

• Do not mix new and used cells or cells from different origins

• Respect the polarities of the cell. Sentences on cell Fire, explosion, and severe burn hazard.

• Do not recharge, crush, disassemble, heat above 212°F(100°C) or incinerate.

• Keep battery out of reach of children and in original package until ready to use.

• Dispose of used batteries promptly




Why choose us?

  • Our commitment to continuous improvement means that our Li-SOCl2 Battery Spiral Type products are always evolving to meet the needs of our clients.
  • We shape and enhance the brand image of enterprise Lithium Battery ER18505M as our development direction and provide customers with efficient, value-added services.
  • We take pride in our ability to create custom Li-SOCl2 Battery Spiral Type solutions that meet the unique needs of our clients.
  • Under the guidance of strong theory, coupled with years of accumulated field experience, our company has achieved the performance that impresses the Lithium Battery ER18505M industry.
  • We are dedicated to providing fast, reliable, and efficient service to our clients for their Li-SOCl2 Battery Spiral Type needs.
  • We always adhere to the concept of quality development and lead the development of the industry by researching and producing 'high, precise and advanced' Lithium Battery ER18505M.
  • We believe that our Li-SOCl2 Battery Spiral Type products provide unparalleled value and reliability to our clients.
  • We promise timely delivery, fine workmanship, and provide quality and satisfactory service.
  • We are committed to delivering high-quality and reliable Li-SOCl2 Battery Spiral Type products to our clients.
  • In the future, we will continue to uphold the concept of symbiosis and insist on creating more value with our technological advantages.

Hot Tags: lithium battery er18505m, China lithium battery er18505m manufacturers, suppliers, Consumer Electronics battery, calorimeter battery, Alarm equipment battery, Numerical control machine battery, Gas meters battery, Automatic instrumentation equipment sensor battery
