Lithium Battery ER14505
video
Lithium Battery ER14505

Lithium Battery ER14505

Model: ER14505
Nominal voltage: 3.6V
Weight: Approx. 19g
Storage temperature: Max. 30℃
Shape: AA

Description

Introduction

The Lithium Battery ER14505 is widely used in various electronic devices. It has excellent performance and characteristics, making it a popular choice for manufacturers. First of all, one of its key features is its high energy density, which means that compared with other types of batteries, it can store more energy in small size. This makes it very suitable for small portable devices that require longer battery life, such as remote control, alarm and sensor. What's more, it is another characteristic of its long shelf life. Its self -discharge rate is low, which means that it can retain 10 years of energy without use. This makes it a reliable choice for emergency backup power and backup applications. Finally, our working temperature range is wide, from -40 ° C to 85 ° C, which allows it to run in a harsh environment. It can also resist impact and vibration, so that it is suitable for use in industry and military applications.


Feature

This is a high -energy density battery widely used in various electronic equipment. It has several unique functions that make it a popular choice among consumers. First of all, the shelf life of Lithium Battery ER14505 is very long. The annual self -discharge rate is less than 1 %, and it can retain its energy for a long time. This feature makes it very suitable for equipment that is not used frequently but requires reliable power supply when needed. Secondly, it provides high energy density. It can store a large amount of energy in the compact size, so that electronic devices can last longer without having to change the battery frequently. In addition, even at extreme temperatures, it runs effectively. It can withstand a wide range of temperatures from -55 ° C to +85 ° C without damage to its performance. This quality makes it suitable for outdoor equipment exposed to different weather conditions. Finally, we have high voltage output. It provides consistent voltage throughout the life, which causes the performance of the electronic device of IT power.

Electrical Characteristics


Model

ER14505

Nominal voltage

3.6V

Nominal capacity

2700mAh ( At 1.0 mA, +25 C, 2.0V cut off. The capacity restored by the cell varies according to current drain, temperature and cut off voltage )

Max. continuous current

65mA (+20°C Capacity will be 50% as per nominal capacity, end voltage 2.0V. Can provide more higher current.)

Max. pulse current

150mA (discharge according to pulse characteristics frequency, continue time, temperature, battery state(storage before use) and it is different as the lowest voltage accepted by device.

Operating temperature range

-60℃~+85℃

Weight

Approx. 19g

Storage temperature

Max. 30℃

Shape

AA

Dimension(max.)

14.5*50.5mm(Diameter*Height)

Battery type

Bobbin Type

Electrolyte/Chemistry

Lithium Thionyl Chloride(Li-SOCl2)

Brand

Ruizhi, Beleader, OEM acceptable

Equivalent

LS14500; TL-4903; SL-360; XL-060F; AA Battery, TL-5903, TL-2100, TL-4903, TL-5104, SL-360/S, SL-760/S, Maxell ER6S-TC,


Certification


Compliance with the European directive CE & RoHS

MSDS, UN38.3 Report, ISO9000


photobank (ER14505)






Why choose us?

  • We provide comprehensive technical support to ensure proper use and maintenance of our Li-SOCl2 Battery Bobbin Type products.
  • Under the background of diversified strategic development, the group began to explore and practice in the Lithium Battery ER14505 industry.
  • We have years of experience producing high-quality Li-SOCl2 Battery Bobbin Type products and have gained a reputation for excellence in the industry.
  • Over the past few years, we have been aggressive and innovating. With our good corporate reputation, unique management style and strong market development capabilities, we have achieved remarkable results one after another.
  • We guarantee fast and reliable delivery of our Li-SOCl2 Battery Bobbin Type products.
  • We constantly believe that one's character decides products' high quality, the details decides products' high-quality, together with the REALISTIC, EFFICIENT AND INNOVATIVE crew spirit for Lithium Battery ER14505.
  • Our Li-SOCl2 Battery Bobbin Type products are ideal for a wide range of applications and industries.
  • Until now our merchandise are now moving on fast and very popular in many countries.
  • Our professional team is dedicated to creating the best Li-SOCl2 Battery Bobbin Type products in the industry.
  • Daring to do is our working state, and being good at doing is the value orientation of our development.

Hot Tags: lithium battery er14505, China lithium battery er14505 manufacturers, suppliers, Smoking Alarm lisocl2 battery, Smart gas metering battery, Kilowatt per-hour meters battery, 3 6V A size battery, TL-5920, Dog Collars battery
